TOSHIBA TLP109(TPL,E, IC-109 OPTOISOLATOR 3.75KV TRANS. 5LEAD SOIC6

TLP109(TPL,E
brand logo

HT Part No. HT208376

Mfr. Part No. TLP109(TPL,E

Manufacturer: TOSHIBA

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0
Units Per Unit Price
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Current Transfer Ratio %20
Isolation Voltage 3750Vrms
Package / Case SO6-5L
Output Current 8mA
Output Voltage 20V
Forward Voltage 1.64V
Rohs ROHS
Manufacturer TOSHIBA
Number of Channel 1
Packaging TAPE&REEL
Features Photocoupler GaAs Ired & Photo-Transistor
Mounting Type SMT
Operating Temperature -55°C~+125°C

More Information

The Toshiba TLP109 is a high-performance optoisolator featuring a 3.75kV isolation voltage, ensuring robust protection between input and output circuits. This 5-lead SOIC6 package device offers reliable signal transmission while effectively isolating noise and transient voltages.

Benefits You Get

  • Enhanced system reliability and safety
  • Improved noise immunity
  • Increased design flexibility
  • Extended product life

Application Potential of the Toshiba TLP109, Optoisolator

  • Industrial Control Systems
  • Power Supplies
  • Motor Drives
  • Medical Equipment
  • Automotive Electronics
