ISOCOM 6N138SMT&R, IC-6N138 OPTO 5KV TRANS. OUTPUT 1CH SMD8

6N138SMT&R
brand logo

HT Part No. HT208223

Mfr. Part No. 6N138SMT&R

Manufacturer: ISOCOM

Technical Documents: Datasheet(datasheets)

994 - In Stock pcs
Price:
£ 0.23
Units Per Unit Price
1 - 999 £ 0.23
1000 + £ 0.20
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Rohs ROHS
Manufacturer ISOCOM
Mounting Type SMT
Package / Case SMD8
Output Voltage 7V
Forward Voltage 1.3V
Packaging TAPE&REEL
Features 8-Pin DIP High Speed Split Darlington Photocoupler
Number of Channel 1
Current Transfer Ratio %300
Output Current 60mA
Isolation Voltage 5000Vrms
Operating Temperature -55°C~+85°C

More Information

The ISOCOM 6N138SMT&R is a compact and high-performance optocoupler designed for reliable signal isolation in a variety of applications. Featuring a single-channel output and an impressive 5kV isolation voltage, this SMD8 packaged device offers exceptional protection against noise and ground loops. Its fast-switching speed and low propagation delay ensure efficient data transmission.

Where Can I Use the ISOCOM 6N138SMT&R, Optocoupler?

  • Industrial Control Systems
  • Automotive Electronics
  • Medical Equipment
  • Power Supplies
  • Telecommunication Systems

Potential Advantages of Using the ISOCOM 6N138SMT&R, Optocoupler

  • Single-channel output for simplicity
  • Fast switching speed and low propagation delay
  • Improved system reliability through isolation
  • Enhanced noise immunity and ground loop prevention
  • Compact size for efficient PCB layout
  • High-speed data transmission capabilities
