TOSHIBA TLP290(GB-TP,SE(T, IC-290 OPTOISOLATOR 3.75KV TRANSISTOR SOIC4

TLP290(GB-TP,SE(T
brand logo

HT Part No. HT208212

Mfr. Part No. TLP290(GB-TP,SE(T

Manufacturer: TOSHIBA

Technical Documents: Datasheet(datasheets)

1159 - In Stock pcs
Price:
£ 0.17
Units Per Unit Price
1 - 2499 £ 0.17
2500 + £ 0.15
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Features Photocoupler GaAs Ired & Photo-Transistor
Manufacturer TOSHIBA
Mounting Type SMT
Package / Case SO4
Number of Channel 1
Current Transfer Ratio %100 - %400
Output Voltage 80V
Output Current 50mA
Isolation Voltage 3750Vrms
Forward Voltage 1.25V
Operating Temperature -55°C~+110°C
Rohs ROHS
Packaging TAPE&REEL

More Information

The Toshiba TLP290(GB-TP,SE(T is a high-performance component designed to provide robust isolation between input and output circuits. Encased in a compact SOIC4 package, this optoisolator features a 3.75kV isolation voltage, ensuring exceptional dielectric strength and protection against voltage surges. Its fast switching speed and high current transfer ratio (CTR) enable efficient signal transmission, making it suitable for demanding applications.

Significant Benefits of Using the Toshiba TLP290(GB-TP,SE(T, Optoisolator

  • Efficient signal transmission for high-speed applications.
  • Reliable signal coupling.
  • Space-saving design.
  • Enhanced system reliability due to robust isolation.
  • Improved system performance through fast switching.
  • Accurate signal transfer enabled by high CTR.
  • Simplified circuit design with compact packaging.

Typical Applications of the Optoisolator Include

  • Industrial Control Systems
  • Power Supplies
  • Motor Drives
  • Medical Equipment
  • Automotive Electronics
