LITEON 4N25-LITEON, IC-4N25 OPTO 5300V TRANS.OUTPUT DIP6 LITEON

4N25-LITEON
brand logo

HT Part No. HT208136

Mfr. Part No. 4N25-LITEON

Manufacturer: LITEON

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0.073
Units Per Unit Price
1 - 64 £ 0.073
65 + £ 0.064
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Manufacturer LITEON
Operating Temperature -55°C~+100°C
Mounting Type THT
Current Transfer Ratio %20
Rohs ROHS
Features Photocoupler
Isolation Voltage 2500Vrms
Package / Case DIP6
Forward Voltage 1.5V
Number of Channel 1
Output Voltage 30V
Output Current 100mA
Packaging TUBE

More Information

The LITEON 4N25-LITEON is a versatile optocoupler featuring a high-voltage output transistor. This DIP-6 packaged device combines a gallium arsenide infrared LED with a silicon NPN phototransistor, offering reliable electrical isolation between input and output circuits. It's designed for applications demanding robust signal transfer and voltage isolation.

Unique Benefits of Using the LITEON 4N25-LITEON, Optocoupler IC

  • Excellent input-to-output isolation
  • Fast switching speed
  • Low current consumption
  • Enhanced system reliability through isolation
  • Protection against voltage spikes and surges
  • Improved noise immunity
  • Flexible design options due to DIP packaging
  • Extended component lifespan through low power consumption

Usage Information of the LITEON 4N25-LITEON, Optocoupler IC

  • Industrial Control Systems
  • Motor Drive Circuits
  • Power Supplies
  • Relay Drivers
  • Solid-State Relays
  • Interface Circuits
  • Input/Output Isolation
