WINSTAR WG320240BX-TTIVZ#000, LCD GRAPHIC 320X240 STN NEGATIVE BLACK RTP

WG320240BX-TTIVZ#000
brand logo

HT Part No. HT204744

Mfr. Part No. WG320240BX-TTIVZ#000

Manufacturer: WINSTAR

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 124.08
Units Per Unit Price
1 - 7 £ 124.08
8 + £ 118.17
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Polarizer / View Direction Transmissive W.T 6:00
Outline Width 109.00mm
Resolution 320x240
LCD Mode STN Negative Black
Interface 6800/8080
Touch Function Resistive Touch
Outline Length 166.80mm
Outline Height 13.00mm
Keyword lcd, lcd graphic, grafik lcd, lcd ekran, 320x240 lcd, winstar
Manufacturer WINSTAR
Controller IC SID13700
Dot Size 0.34x0.34mm
Typical Supply Voltage N/A
View Area 122.00x92.00mm
Backlight Type LED, White
Packaging BOX

More Information

The WINSTAR WG320240BX-TTIVZ#000 is a high-quality LCD graphic module that brings exceptional clarity and performance to your visual display needs. With a resolution of 320x240 pixels, this STN negative black display ensures sharp and crisp visuals, making it ideal for detailed graphical applications. The integrated Resistive Touch Panel (RTP) enhances its functionality, providing an intuitive user interface for a wide range of applications. Designed for versatility and durability, this module is perfect for both industrial and consumer electronics. Its sleek black background with high contrast makes it easy to read in various lighting conditions.

Standout Features of the WINSTAR WG320240BX-TTIVZ#000, LCD Graphic Module

  • Delivers sharp and detailed graphics.
  • Provides high contrast for easy readability.
  • Enables interactive and user-friendly interfaces.
  • Suitable for various environmental conditions.
  • Fits seamlessly into space-constrained applications.

What Benefits Does It Offer?

  • Enhanced Visual Clarity: Ensures your graphics and text are always sharp and legible.
  • User Interaction: The touch panel allows for easy and intuitive control.
  • Reliable Performance: Built to perform consistently in different environments.
  • Easy Integration: Compact size allows for effortless incorporation into existing designs.

Usage Information of the WINSTAR WG320240BX-TTIVZ#000, LCD Graphic Module

  • Industrial Equipment: Used in machinery displays and control panels.
  • Medical Devices: Ideal for diagnostic and monitoring equipment.
  • Consumer Electronics: Perfect for user interfaces in various gadgets.
  • Automotive Displays: Suitable for dashboards and infotainment systems.
  • Home Automation: Enhances the functionality of smart home devices.
