TEXAS CD74HCT138E, IC DECODER/DEMUX 1X3:8 16DIP

CD74HCT138E
brand logo

HT Part No. HT304224

Mfr. Part No. CD74HCT138E

Manufacturer: TEXAS

Technical Documents: Datasheet(datasheets)

866 - In Stock pcs
Price:
£ 0.26
Units Per Unit Price
1 - 24 £ 0.26
25 + £ 0.23
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Logic Type Decoder/Demultiplexer
Features High-Speed CMOS Logic 3- to 8-Line Decoder/Demultiplexer Inverting and Noninverting
Manufacturer TEXAS
Mounting Type THT
Package / Case DIP16
Circuits 1 x 3:8
Output Current (High, Low) 4mA,4mA
Supply Voltage 4.5V to 5.5V
Operating Temperature -55°C~+125°C
Rohs ROHS
Packaging TUBE

More Information

The TEXAS CD74HCT138E is a high-performance, 3-to-8-line decoder/demultiplexer packaged in a standard 16-pin DIP. This versatile IC efficiently converts 3-bit binary input codes into eight mutually exclusive active-low outputs. Designed for compatibility with CMOS and TTL logic levels, the CD74HCT138E offers reliable operation and low power consumption, making it a preferred choice for a wide range of digital systems.

Core Characteristics of the TEXAS CD74HCT138E, Decoder/Demultiplexer

  • High-speed operation
  • Low-power consumption
  • Compatible with CMOS and TTL logic levels

Benefits for You

  • Efficient data distribution
  • Reduced power consumption
  • Simplified circuit design
  • Increased system reliability

Typical Uses of the TEXAS CD74HCT138E, 3-to-8 Line Decoder/Demultiplexer

  • Memory Address Decoding
  • Output Enable Control
  • Data Selection
  • Digital System Control
