RALTRON AS-22.1184-20-TR, CRYSTAL 22.1184MHZ HC49S 20pF SHORT

AS-22.1184-20-TR
brand logo

HT Part No. HT205411

Mfr. Part No. AS-22.1184-20-TR

Manufacturer: RALTRON

Technical Documents:

226 - In Stock pcs
Price:
£ 0.21
Units Per Unit Prices
1 - 999 £ 0.21
1000 + £ 0.18
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Operating Temperature -20°C~+70°C
Equivalent Series Resistance (ESR) 40 Ohms
Width 5.00mm
Manufacturer RALTRON
Frequency Tolerance ±30PPM
Packaging TAPE&REEL
Series AS
Package / Case HC-49S
Diameter N/A
Length 11.40mm
Mounting Type THT
Frequency 22.1184MHz
Capacitance 20pF
Frequency Stability ±50PPM
Applications N/A
Height 3.50mm
Rohs ROHS

More Information

The RALTRON AS-22.1184-20-TR is a precision 22.1184 MHz crystal oscillator housed in a compact HC49S package. Designed for optimal performance and reliability, this crystal features a 20pF load capacitance and exhibits excellent frequency stability over a wide temperature range. Ideal for applications demanding precise timing and synchronisation, this crystal offers superior quality and durability, making it a trusted component for various electronic devices.

Possible Advantages of Using the RALTRON AS-22.1184-20-TR, 22.1184 MHz Crystal Oscillator

  • Excellent frequency stability
  • Reliable performance in harsh environments
  • Low phase noise for clean signal output
  • Long-term stability for accurate timing
  • Easy integration into circuit designs

The RALTRON AS-22.1184-20-TR, 22.1184 MHz Crystal Oscillator: Use Cases

  • Wireless Communication Systems
  • GPS Modules
  • Industrial Control Equipment
  • Medical Devices
  • Telecommunication Infrastructure
