ANSEN AS49SD-13.225625M-FE120E, CRYSTAL 13.225625MHZ HC49SMT 12pF 30ppm SMD TR

AS49SD-13.225625M-FE120E
brand logo

HT Part No. HT205352

Mfr. Part No. AS49SD-13.225625M-FE120E

Manufacturer: ANSEN

Technical Documents: Datasheet(datasheets)

745 - In Stock pcs
Price:
£ 0.17
Units Per Unit Price
2 - 199 £ 0.17
200 + £ 0.15
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package / Case HC-49S
Equivalent Series Resistance (ESR) 40 Ohms
Width 4.80mm
Operating Temperature -10°C~+70°C
Manufacturer ANSEN
Diameter N/A
Height 4.20mm
Rohs ROHS
Mounting Type SMT
Series AS49SD
Frequency 13.225625MHz
Length 11.50mm
Capacitance 12pF
Frequency Tolerance ±30PPM
Frequency Stability ±30PPM
Applications N/A
Packaging BULK

More Information

The ANSEN AS49SD-13.225625M-FE120E is a high-performance crystal oscillator designed to provide precision frequency control in a wide range of electronic applications. Operating at a frequency of 13.225625 MHz, this surface-mount device (SMD) is housed in the compact and reliable HC49SMT package. With a load capacitance of 12pF and an exceptional frequency stability of ±30ppm, this crystal is engineered to deliver consistent, reliable performance even in demanding environments. Its robust design ensures long-term reliability, making it perfect for engineers and designers seeking a dependable timing solution.

Significant Benefits of Using the ANSEN AS49SD-13.225625M-FE120E, Crystal Oscillator

  • Ensures precise frequency control in electronic circuits
  • Compact design saves space on the PCB
  • High reliability and long-term stability
  • Easy integration into existing designs
  • Ideal for use in environments requiring high stability and accuracy

Typical Uses of the ANSEN AS49SD-13.225625M-FE120E, Crystal Oscillator

  • Communication Systems
  • Microprocessors and Microcontrollers
  • Timing Circuits
  • RF Applications
  • Embedded Systems
