INTERSIL ICMF214P101MFR, FILTER 100MhZ 100R COMMON MODE INNOCHIPS

ICMF214P101MFR
brand logo

HT Part No. HT259917

Mfr. Part No. ICMF214P101MFR

Manufacturer: INTERSIL

Technical Documents: Datasheet(datasheets)

3892 - In Stock pcs
Price:
£ 0.16
Units Per Unit Price
2 - 3999 £ 0.16
4000 + £ 0.14
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Pitch None
Filter Type Data Line Filter
Shielding Unshielded
Current 100mA
Mounting Type SMT
Applications N/A
Width 1.20mm
Package / Case 0805 (2012 Metric)
Number of Lines 4
Tolerance ±25%
Rohs ROHS
Manufacturer INTERSIL
Series ICMF
Technology Ceramic Multilayer
Inductance None
Impedance 100 Ohms
DC Resistance (DCR) N/A
Diameter N/A
Length 2.00mm
Height 0.80mm
Operation Temperature -40°C ~ +85°C
Packaging TAPE&REEL

More Information

The INTERSIL ICMF214P101MFR is a high-performance common-mode filter designed to suppress unwanted noise and interference in electronic systems. This compact 100 MHz filter features a 100 Ohm impedance, making it ideal for a variety of applications where signal integrity is critical. With its robust construction and advanced filtering capabilities, the ICMF214P101MFR effectively protects sensitive circuitry from electromagnetic interference (EMI) and radio frequency interference (RFI).

Significant Benefits of Using the INTERSIL ICMF214P101MFR, Common-Mode Filter

  • Excellent common-mode impedance
  • Robust construction
  • Improved signal quality
  • Enhanced system performance
  • Reduced EMI/RFI emissions
  • Increased design flexibility

Use Cases of the INTERSIL ICMF214P101MFR, Common-Mode Filter

  • Power Supply Filtering
  • High-Speed Data Lines
  • Audio and Video Equipment
  • Industrial Control Systems
