SDW04F1C J2B5E-V0 - LED COB 37W CW 5300-5600K 3400-3900LM@700mA

SDW04F1C J2B5E-V0
brand logo

HT Part No. HT303219

Mfr. Part No. SDW04F1C J2B5E-V0

Manufacturer: SEOUL

Technical Documents:

6 - In Stock pcs
Price:
£ 2.30
Units Per Unit Prices
1 - 11 £ 2.30
12 + £ 2.10
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Length 28.00mm
Series ZC25
Forward Current 960mA
Width 28.00mm
Power 26W
Luminous Flux (25°C) 3400-3900lm
Forward Voltage 37V
Thermal Resistance 0.40K/W
CCT 5300-5600K
Test Current 700mA
Height 2.30mm
Operating Temperature -40°C~+85°C
Rohs ROHS
Packaging TRAY
Manufacturer SEOUL
Color Cool White
Max Power 36.90W
Luminous Flux (85°C) N/A
CRI 70
View Angle 120°
Keyword led, led aydınlatma, cob, cob led, chip on board led, seoul cob

More Information

The SDW04F1C J2B5E-V0 is a high-performance Chip-on-Board (COB) LED that delivers a powerful, cool white light output. With a power rating of 37 watts, this LED is designed to provide high luminosity and efficiency, making it an excellent choice for a variety of lighting applications. The COB technology ensures a uniform light distribution and high thermal conductivity, enhancing the overall performance and longevity of the LED.

Key Features & Benefits of the LED:

  • High Luminosity: Delivers a bright, cool white light with superior intensity.
  • Efficiency: Consumes only 37 watts of power while providing optimal light output.
  • Uniform Light Distribution: COB technology ensures even light dispersion with minimal shadowing.
  • Thermal Management: Excellent thermal conductivity extends the lifespan of the LED by efficiently dissipating heat.
  • Durability: Robust construction for long-lasting performance, suitable for demanding environments.
  • Colour Quality: High Color Rendering Index (CRI) ensures accurate colour representation, enhancing visual clarity and appeal.

Applications of SDW04F1C J2B5E-V0, COB LED:

  • Commercial Lighting
  • Industrial Lighting
  • Residential Lighting
  • Architectural Lighting
  • Street Lighting
  • Display and Exhibition Lighting.
