SDW03F1C H1C2E-V0 - LED COB 24W CW 5000-5300K 1800-2400LM@500mA

SDW03F1C H1C2E-V0
brand logo

HT Part No. HT303203

Mfr. Part No. SDW03F1C H1C2E-V0

Manufacturer: SEOUL

Technical Documents:

20 - In Stock pcs
Price:
£ 10.42
Units Per Unit Prices
1 - 19 £ 10.42
20 + £ 9.73
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Max Power 24.40W
CCT 5000-5300K
Height 2.30mm
Packaging TRAY
Series ZC18
Forward Current 640mA
Width 19.00mm
Rohs ROHS
Manufacturer SEOUL
Forward Voltage 37V
Test Current 500mA
View Angle 120°
Luminous Flux (25°C) 1800-2400lm
Luminous Flux (85°C) N/A
Length 19.00mm
Operating Temperature -40°C~+85°C
Color Cool White
Power 18.60W
CRI 70
Thermal Resistance 0.70K/W
Keyword led, led aydınlatma, cob, cob led, chip on board led, seoul cob

More Information

The SDW03F1C H1C2E-V0 is a high-performance COB LED module designed for applications requiring bright, cool white illumination. It integrates advanced technology to deliver efficient lighting solutions with enhanced reliability and longevity.

Features & Benefits of the LED:

  • High Performance: This product provides 24W of power with superior luminous efficacy, ensuring bright and clear cool white light output.
  • Compact Design: COB (Chip-on-Board) technology allows a compact size, making it suitable for space-constrained installations.
  • Energy Efficient: Offers significant energy savings compared to traditional lighting sources, contributing to lower operational costs.
  • Long Lifespan: Designed for long-term use with a lifespan of up to 50,000 hours.
  • Excellent Thermal Management: Efficient thermal dissipation ensures stable performance and extends LED longevity.
  • Wide Input Voltage Range: Operates effectively across a broad range of input voltages, enhancing versatility in various applications.

Broad-Range Applications of SDW03F1C H1C2E-V0 COB LED:

The SDW03F1C H1C2E-V0 COB LED module is ideal for a variety of applications, including:

  • Architectural Lighting
  • Commercial Lighting
  • Industrial Lighting
  • Display Lighting
  • Street Lighting.
