SDW01F1C DB1E-V0 - LED COB 12W CW 5300-5600K 800-900LM@180mA

SDW01F1C DB1E-V0
brand logo

HT Part No. HT303184

Mfr. Part No. SDW01F1C DB1E-V0

Manufacturer: SEOUL

Technical Documents:

29 - In Stock pcs
Price:
£ 0.74
Units Per Unit Prices
1 - 29 £ 0.74
30 + £ 0.64
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
CCT 5300-5600K
Length 13.50mm
Width 13.50mm
Color Cool White
Luminous Flux (85°C) N/A
Forward Voltage 37V
Manufacturer SEOUL
Series ZC6
Rohs ROHS
Keyword led, led aydınlatma, cob, cob led, chip on board led, seoul cob
Max Power 12.30W
Forward Current 320mA
Test Current 180mA
Height 2.30mm
Operating Temperature -40°C~+85°C
Power 6.70W
Luminous Flux (25°C) 800-900lm
CRI 70
View Angle 120°
Thermal Resistance 1.40K/W
Packaging TRAY

More Information

The SDW01F1C DB1E-V0 COB LED in Cool White, 12W, represents a high-performance Chip-on-Board (COB) LED module designed for efficient illumination solutions. It integrates advanced COB technology to deliver a concentrated beam of cool white light, which is ideal for various lighting applications.

Unique Features and Benefits of SDW01F1C DB1E-V0 COB LED:

  • COB Technology: Integrates Chip-on-Board technology for enhanced brightness and efficiency.
  • Cool White Light: Provides a crisp and clear cool white illumination suitable for a wide range of environments.
  • High Power Efficiency: Operates at 12W with optimized energy consumption.
  • Compact Design: Compact form factor enables versatile installation options in compact spaces.
  • Long Lifespan: Offers a long operational lifespan, minimizing maintenance needs.
  • Excellent Color Rendering: Ensures accurate color representation for improved visibility.
  • Instant Start: Provides instant full brightness without warm-up time, suitable for dynamic lighting applications.

Versatile Applications of SDW01F1C DB1E-V0 COB LED:

  • Commercial Lighting: Suitable for retail displays, galleries, and offices.
  • Residential Lighting: Ideal for task lighting, under-cabinet fixtures, and ambient lighting.
  • Architectural Lighting: Used in accent lighting for architectural features and landscapes.
  • Industrial Use: Applied in machinery illumination and inspection lighting due to its robust design and bright output.
