NXP (PHILIPS) HEF4046BT653, Phase-Locked Loop IC, SO16

The NXP (PHILIPS) HEF4046BT653 is a versatile Phase-Locked Loop (PLL) IC housed in an SO16 package. It integrates a voltage-controlled oscillator (VCO), phase comparators, and a range of additional features, making it ideal for frequency synthesis, demodulation, and signal recovery applications. This IC is designed to provide high performance with low power consumption and is suitable for a variety of electronic systems requiring precise frequency control and stability.

Unique Benefits of Using the NXP (PHILIPS) HEF4046BT653, Phase-Locked Loop

• Integrated VCO with a wide frequency range
• Two-phase comparators (PC1 and PC2)
• Ensures accurate frequency control and stability
• Reduces power consumption, ideal for battery-operated devices
• Simplifies design with an integrated solution
• Enhances signal integrity with low-phase noise
• Effortless to use in limited spaces due to its SO16 package
• Increases system reliability with lock detection

Usage Information of the NXP (PHILIPS) HEF4046BT653, Phase-Locked Loop

• Frequency Synthesis in Communication Systems
• Demodulation in RF Receivers
• Signal Recovery in Data Communication
• Clock Generation and Distribution
• Phase Modulation and Demodulation
• Frequency Multiplication and Division
