HS75 220R J - RES.AL.CLAD 75W 220 Ohms 5% WIREWOUND CHASSIS

HS75 220R J
brand logo

HT Part No. HT258488

Mfr. Part No. HS75 220R J

Manufacturer: ARCOL

Technical Documents: Datasheet(datasheets)

91 - In Stock pcs
Price:
£ 7.74
Units Per Unit Price
1 - 59 £ 7.74
60 + £ 7.03
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Temperature Coefficient ±100PPM/°C
Packaging BULK&BOX
Tolerance ±5%
Applications General Purpose
Width 47.50mm
Composition Wire Wound
Diameter N/A
Length 72.50mm
Pin Type Axial
Power 75W
Height 24.10mm
Manufacturer ARCOL
Mounting Type Chassis
Special Feature N/A
Resistance Value 220 Ohms
Working Voltage 1400V
Rohs ROHS
Keyword 220R

More Information

The ARCOL HS75 220R J is a high-power, wire-wound resistor designed for demanding electronic applications. It is known for its robust construction and reliability. It is a 75-watt wire-wound resistor with a resistance value of 220 ohms and a tolerance of 5%. It features an aluminium-clad design, which enhances its heat dissipation capabilities, making it suitable for high-power applications.

Unique Features and Benefits of the ARCOL HS75 220R J, Wirewound Resistor

  • High Power Handling: Can handle up to 75 watts, ideal for high-power circuits.
  • Heat Dissipation: Aluminum cladding helps in efficient heat management.
  • Durability: Robust construction ensures long-term reliability.
  • Precision: 5% tolerance ensures a good balance between performance and cost.

Application Areas of the Wirewound Resistor

The ARCOL HS75 220R J resistor is a versatile and reliable component that offers high performance and durability for various electronic and electrical applications, such as:

  • Power Supplies: Used in power supply circuits for voltage regulation and current limiting.
  • Amplifiers: Essential for managing power in audio and radio frequency amplifiers.
  • Motor Drives: Utilised in motor control circuits for industrial applications.
  • Load Testing: Suitable for use in load banks for testing power equipment.
  • Electric Vehicles: Applied in power management systems in electric and hybrid vehicles.
