VMS-R680-1.0-U - RES.SHUNT (6432) 2512 680m Ohms 1% 4W AUTO SMT

VMS-R680-1.0-U
brand logo

HT Part No. HT203236

Mfr. Part No. VMS-R680-1.0-U

Manufacturer: ISABELLENHÜTTE

Technical Documents: Datasheet(datasheets)

359 - In Stock pcs
Price:
£ 0.73
Units Per Unit Price
1 - 8999 £ 0.73
9000 + £ 0.64
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Manufacturer ISABELLENHÜTTE
Series VMS
Mounting Type SMT
Package / Case 2512 Case
Material N/A
Resistance Value 680m Ohms
Tolerance ±1%
Power 3W
Applications Automotive(AEC-Q200)
Diameter N/A
Length N/A
Width N/A
Height N/A
Temperature Coefficient ±20ppm/°K
Rohs ROHS
Packaging TAPE&REEL
Keyword 0.68R

More Information

The ISABELLENHÜTTE VMS-R680-1.0-U is a high-precision shunt resistor uniquely designed for accurate, current measurement applications. This surface-mount technology (SMT) resistor stands out with its 680 milliohms resistance, 1% tolerance, and power rating of up to 4 watts. Encased in a 6432 (2512) package, it is an ideal choice for various applications where precise current sensing is crucial.

Technical Insights of the Shunt Resistor

  • High power rating (4W)
  • Low resistance (680m Ohms) for minimal power loss
  • Tight tolerance (1%) for accurate measurements
  • Robust construction suitable for harsh environments

What Are the Potential Benefits of the ISABELLENHÜTTE VMS-R680-1.0-U, Shunt Resistor - 6432 (2512) 680m Ohms 1% 4W Auto SMT?

  • Enhanced measurement accuracy
  • Improved efficiency in current sensing applications
  • Reliable performance in high-power circuits
  • Ideal for automated assembly processes due to SMT design

Application Information of the ISABELLENHÜTTE VMS-R680-1.0-U, Shunt Resistor

  • Automotive electronics for battery management and electric vehicles
  • Industrial control systems for precise current monitoring
  • Power management systems in renewable energy setups
  • Consumer electronics requiring high-precision current measurement
