PANJIT B10SR200001, DIODE BRIDGE 0.5A 1000V 1PH 7*2.3mm SMD T/R PANJIT

B10S_R2_00001
brand logo

HT Part No. HT298065

Mfr. Part No. B10S_R2_00001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

1200299 - In Stock pcs
Price:
£ 0.089
Units Per Unit Price
2 - 2999 £ 0.089
3000 + £ 0.073
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Rohs ROHS
Manufacturer PANJIT
Packaging TAPE&REEL
Package / Case 4-SMD (MDI)
Applications N/A
Series Standard
Current - DC Forward (If) (Max) 800mA
Diode Type Single Phase
Mounting Type SMT
Voltage - Peak Reverse (Max) 1kV
Reverse Current (25°C) 5uA
Operating Temperature -55°C~+150°C

More Information

The PANJIT B10SR200001 is a single-phase surface-mount diode bridge rectifier with a maximum average forward rectified current of 0.5A and a peak reverse voltage of 1000V. It features a compact 7x2.3mm package size, making it suitable for various space-constrained applications.

Unique Benefits Offered By the PANJIT B10SR200001, Single-Phase Surface-Mount Diode Bridge Rectifier

  • Low thermal resistance for better heat dissipation
  • Operates efficiently in a wide temperature range
  • Compact size allows for use in space-limited designs
  • Suitable for high voltage applications up to 1000V
  • SMD package simplifies PCB design and assembly
  • Consistent and reliable rectification for improved circuit stability
  • Low thermal resistance enhances performance and longevity

Where Can You Employ the PANJIT B10SR200001, Single-Phase Surface-Mount Diode Bridge Rectifier?

This diode bridge rectifier is a versatile component, providing efficient and reliable rectification in a variety of electronic applications, such as:

  • Power Supplies: Ideal for converting AC to DC in power supply units
  • Battery Chargers: Used in battery charging circuits for efficient rectification
  • Consumer Electronics: Suitable for use in various electronic devices requiring AC to DC conversion
  • Industrial Equipment: Applied in industrial control systems and equipment
  • Telecommunication: Utilised in telecom systems for power management and rectification
