ANALOGDEVICES AD8334ACPZ, IC-8334 VGA QUAD W/PREAMP 64LFCSP

AD8334ACPZ
brand logo

HT Part No. HT206955

Mfr. Part No. AD8334ACPZ

Manufacturer: ANALOGDEVICES

Technical Documents: Datasheet(datasheets)

29 - In Stock pcs
Price:
£ 24.24
Units Per Unit Price
1 - 249 £ 24.24
250 + £ 22.65
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Amplifier Type Variable Gain Amplifiers
Features Ultralow Noise VGAs with Preamplifier and Programmable RIN
Manufacturer ANALOGDEVICES
Mounting Type SMT
Package / Case LFCSP64-VQ
Number of Channels N/A
Bandwidth N/A
Supply Voltage 4.5V to 5.5V
Supply Current N/A
Input Offset Voltage N/A
Operating Temperature -40°C~+85°C
Rohs ROHS
Packaging TRAY

More Information

The Analog Devices AD8334ACPZ is a high-performance quad VGA amplifier with integrated preamplifiers optimised for low-voltage, battery-powered applications. Housed in a compact 64-lead LFCSP package, this device offers exceptional performance in terms of gain accuracy, bandwidth, and power consumption. It delivers robust signal conditioning for VGA sensor interfacing.

Typical Applications of the Quad VGA Amplifier

  • Portable Medical Equipment (ECG, EEG, etc.)
  • Industrial Process Control and Automation
  • Automotive Sensors and Electronics
  • Data Acquisition Systems
  • Consumer Electronics

Unique Features and Benefits of the Analog Devices AD8334ACPZ, Quad VGA Amplifier

  • Low power consumption for battery-operated systems
  • High gain accuracy and bandwidth
  • Robust performance in challenging environments
  • Extended battery life due to low power usage
  • Improved signal integrity and accuracy
  • Smaller PCB footprint and reduced system cost
  • Reliable operation in harsh conditions
  • Easy integration into existing designs
