TEXAS ADS1230IPWR, IC-1230 ADC 20-BIT 10/80SPS 16-TSSOP

ADS1230IPWR
brand logo

HT Part No. HT193926

Mfr. Part No. ADS1230IPWR

Manufacturer: TEXAS

Technical Documents: Datasheet(datasheets)

2164 - In Stock pcs
Price:
£ 3.03
Units Per Unit Price
1 - 1999 £ 3.03
2000 + £ 2.76
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Features 20-Bit ADC for Bridge Sensors
Manufacturer TEXAS
Mounting Type SMT
Package / Case TSSOP16
Resolution 20-Bit
Supply Voltage 2.7V to 5.3V
Input Type Differential
Interface SPI
Number of Channel 1
Operating Temperature -40°C~+85°C
Rohs ROHS
Packaging TAPE&REEL

More Information

The TEXAS ADS1230IPWR is a precision 20-bit analogue-to-digital converter (ADC) with a highly integrated design, ideal for low-power applications. It operates at two data rates, 10 and 80 samples per second (SPS), offering flexibility in balancing speed and resolution. This ADC features a low-noise, high-gain programmable gain amplifier (PGA) and an internal oscillator, simplifying the design process by reducing the need for external components. It operates on a single supply voltage of 2.7V to 5.3V, making it suitable for a wide range of applications. The ADS1230IPWR is housed in a compact 16-TSSOP package, providing space efficiency for dense designs.

Salient Features and Benefits of Using the TEXAS ADS1230IPWR, Analogue to Digital Converter

  • 20-bit resolution for high precision
  • Integrated PGA with low noise
  • Internal oscillator
  • High accuracy and resolution for precise measurements
  • Flexible data rates for different application needs
  • Simplified design with integrated components
  • Compact package size

Application Potential of the TEXAS ADS1230IPWR, Analogue to Digital Converter

  • Weigh Scales
  • Industrial Process Control
  • Medical Instrumentation
  • Portable Instrumentation
  • Data Acquisition Systems
