L7985ATR - IC-7985 V.REG-2A 8-PWRSOIC ST

L7985ATR
brand logo

HT Part No. HT271928

Mfr. Part No. L7985ATR

Manufacturer: STM

Technical Documents:

29 - In Stock pcs
Price:
£ 1.70
Units Per Unit Prices
1 - 2499 £ 1.70
2500 + £ 1.55
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Features 2A Step Down Switching Buck Regulator
Manufacturer STM
Mounting Type SMT
Package / Case HSOP8
Switching Function Step Down
Output Type Adjustable
Output Voltage 0.6V to 38V
Input Voltage 4.5V to 38V
Output Current 2A
Switching Frequency 250kHz to 1MHz
Rohs ROHS
Packaging TAPE&REEL
OperatingTemperature -40°C~+150°C

More Information

The STM L7985ATR is a high-efficiency, monolithic, step-down switching regulator designed for a wide range of applications. This integrated circuit provides a regulated 2A output current in an 8-PWRSOIC package, making it ideal for space-constrained environments.

Standout Features and Benefits of Using the STM L7985ATR Step-Down Switching Regulator

  • Switching frequency: adjustable up to 1.5 MHz
  • Thermal shutdown and current limit protection
  • Soft-start and enable pin
  • High efficiency reduces power loss and heat generation
  • Wide input voltage range supports various power sources
  • Compact 8-PWRSOIC package saves board space
  • Adjustable switching frequency optimises performance for specific applications
  • Built-in protection features enhance reliability
  • Soft-start functionality prevents inrush currents

Versatile Usage of the STM L7985ATR, Step-Down Switching Regulator

  • Point-of-Load Regulation for Microprocessors and DSPs
  • Distributed Power Systems
  • Battery-Powered Equipment
  • Industrial Control Systems
  • Consumer Electronics
  • Automotive Power Supplies
