IXYS CLA30E1200HB, THYRISTOR DIS.SINGLE 30A 1200V TO247-3 THT

CLA30E1200HB
brand logo

HT Part No. HT256334

Mfr. Part No. CLA30E1200HB

Manufacturer: IXYS

Technical Documents: Datasheet(datasheets)

26366 - In Stock pcs
Price:
£ 1.86
Units Per Unit Price
1 - 29 £ 1.86
30 + £ 1.69
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Series Thyristor Phase Control
Trr N/A
Junction Temperature (Tj) N/A
Current On State (ITav) 30A
Gate Trigger (Vgt) 1.3V
Tq 150us
Applications N/A
Mounting Type THT
Package / Case TO247-3
Current Temperature (IC) 120°C
Current Hold (IH) 60mA
Power Dissipation 250W
Rohs ROHS
Manufacturer IXYS
RMS On State (ITrms) 47A
Voltage (VRRM) 1.2kV
Forward Drop (VT) 1.28V
Configuration Single
Operating Temperature -40°C~+150°C
Packaging TUBE

More Information

The IXYS CLA30E1200HB is a high-performance, single thyristor device designed for efficient control of high power. It operates with a current rating of 30A and a voltage rating of 1200V, housed in a robust TO247-3 package suitable for through-hole technology (THT) mounting.

Advanced Attributes of the IXYS CLA30E1200HB, Single Thyristor

  • TO247-3 package
  • Through-hole technology (THT) mounting
  • Low thermal resistance
  • High surge capability
  • Fast switching times

What Benefits Does It Offer?

  • Efficient power control in high-demand applications
  • Enhanced durability and reliability due to robust packaging
  • Easy to mount and integrate into existing designs
  • Superior thermal management ensures long-lasting performance
  • Capable of handling high surge currents without damage
  • Fast switching enhances performance in dynamic applications

Application Information of the IXYS CLA30E1200HB, Single Thyristor

  • Motor Control Circuits
  • AC and DC Power Control Systems
  • Voltage Regulation
  • Inverter Circuits
  • Power Converters
  • Industrial Heating and Lighting Systems
  • Battery Chargers
