IXYS CMA80PD1600NA, THYRISTOR DIODE MOD.DUAL 80A 1600V SOT227B CHASSIS

CMA80PD1600NA
brand logo

HT Part No. HT190606

Mfr. Part No. CMA80PD1600NA

Manufacturer: IXYS

Technical Documents: Datasheet(datasheets)

285 - In Stock pcs
Price:
£ 20.62
Units Per Unit Price
1 - 9 £ 20.62
10 + £ 19.27
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Voltage (VRRM) 1.6kV
Power Dissipation 270W
Trr N/A
Packaging TUBE
Series Thyristor Phase Control
Mounting Type Chassis
Current On State (ITav) 80A (2x80A)
Gate Trigger (Vgt) 1.5V
Manufacturer IXYS
RMS On State (ITrms) 126A (2x126A)
Forward Drop (VT) 1.3V
Applications N/A
Package / Case SOT227B (Minibloc)
Current Temperature (IC) 80°C
Current Hold (IH) 200mA
Tq 150us
Configuration Dual
Junction Temperature (Tj) N/A
Operating Temperature -40°C~+125°C
Rohs ROHS

More Information

The IXYS CMA80PD1600NA is a dual thyristor diode module capable of handling high currents and voltages. It is designed for industrial power control applications and offers a robust solution for high-power applications, ensuring reliable performance and efficient operation across various industrial sectors.

Impressive Features and Benefits of Using the IXYS CMA80PD1600NA, Dual Thyristor Diode

  • Dual module integrating both thyristors and diodes.
  • High reliability and rugged construction suitable for harsh environments.
  • Enables efficient power switching and control.
  • Reduces losses with low forward voltage drop.
  • Increases system reliability due to robust design.
  • Simplifies installation with the chassis-mount package.

Usage Information of the IXYS CMA80PD1600NA, Dual Thyristor Diode

  • Industrial Motor Drives
  • Power Supplies
  • Welding Equipment
  • Battery Chargers
  • Renewable Energy Systems
