N0392WC120-U9900 - THYRISTOR DISC SINGLE 392A 1200V CHASSIS

N0392WC120-U9900
brand logo

HT Part No. HT190100

Mfr. Part No. N0392WC120-U9900

Manufacturer: IXYS WESTCODE

Technical Documents: Datasheet(datasheets)

1 - In Stock pcs
Price:
£ 55.96
Units Per Unit Price
1 - 23 £ 55.96
24 + £ 52.30
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Current Hold (IH) 600mA
Operating Temperature -40°C~+125°C
Package / Case Disc (W8)
Tq 125us
Junction Temperature (Tj) N/A
Mounting Type Chassis
Current On State (ITav) 392A
Current Temperature (IC) 55°C
Configuration Single
Manufacturer IXYS WESTCODE
Series Thyristor Phase Control
Gate Trigger (Vgt) 3V
Applications N/A
Packaging BOX
RMS On State (ITrms) 776A
Voltage (VRRM) 1.2kV
Forward Drop (VT) 1.68V
Power Dissipation N/A
Trr 9us
Rohs NON ROHS

More Information

A Thyristor Disc Single N0392WC120-U9900 is a solid-state semiconductor device used to regulate high-power currents. It functions like a switch, turning on and off based on a control signal.

Features of Thyristor Disc Single N0392WC120-U9900:

  • High current handling capacity (392A)
  • High voltage rating (1200V)
  • Single disc construction
  • Likely a compact design for chassis mounting

Types of the Product:

Thyristor discs come in various types depending on factors like voltage rating, current handling, and switching speed.

Typical Applications of Thyristor Disc Single N0392WC120-U9900:

Thyristor discs find use in various applications requiring high-power control, including:

  • AC power control
  • DC motor control
  • Battery chargers
  • Inverters.
