VISHAY IHLP2525CZER220M8A, FIXED INDUCTOR 22UH 2.8A 174 MOHM SMD

IHLP2525CZER220M8A
brand logo

HT Part No. HT194985

Mfr. Part No. IHLP2525CZER220M8A

Manufacturer: VISHAY

Technical Documents: Datasheet(datasheets)

3761 - In Stock pcs
Price:
£ 0.51
Units Per Unit Price
1 - 1999 £ 0.51
2000 + £ 0.46
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Shielding Shielded
Height 3.00mm
Rohs ROHS
Manufacturer VISHAY
Package / Case Non Standard
Technology Molded
DC Resistance (DCR) 163m Ohms
Series IHLP
Applications Automotive(AEC-Q200)
Length 6.47mm
Width 6.47mm
Inductance 22uH
Current Rating 2.8A
Current - Saturation (Isat) N/A
Operation Temperature -55°C ~ +180°C
Mounting Type SMT
Pitch None
Tolerance ±20%
Diameter N/A
Packaging TAPE&REEL

More Information

The VISHAY IHLP2525CZER220M8A is a high-performance fixed inductor designed to address the demands of modern electronic applications. This Surface Mount Device (SMD) inductor offers an inductance of 22µH, a current rating of 2.8A, and a low DC resistance of 174mΩ. Its compact design is optimised for space-constrained applications, ensuring efficient power management and signal filtering. Featuring a high saturation current, the IHLP2525CZER220M8A is well-suited for handling transient load conditions, making it an ideal choice for power supply circuits and DC-DC converters.

Benefits for You

  • High saturation current
  • Efficient power management
  • Reliable performance under transient conditions
  • Space-saving design
  • Enhanced thermal performance

Versatile Uses of the VISHAY IHLP2525CZER220M8A, Fixed Power Inductor

This versatile inductor ensures optimal performance and reliability, making it an excellent choice for various electronic applications, including:

  • Power Supply Circuits
  • DC-DC Converters
  • Signal Filtering
  • Telecommunications Equipment
  • Computing and Networking Devices
