KWL1608CR10STF - INDUCTOR FIXED (1608) 0603 100NH SMD

KWL1608CR10STF
brand logo

HT Part No. HT194983

Mfr. Part No. KWL1608CR10STF

Manufacturer: GALAXY

Technical Documents: Datasheet(datasheets)

920 - In Stock pcs
Price:
£ 0.10
Units Per Unit Price
5 - 3999 £ 0.10
4000 + £ 0.097
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Pitch None
Current - Saturation (Isat) N/A
Height 0.80mm
Shielding Shielded
Tolerance ±5%
Applications General Purpose
Operation Temperature -55°C ~ +125°C
Series KWL
Package / Case 0603 (1608 Metric)
Current Rating 470mA
DC Resistance (DCR) 540m Ohms
Manufacturer GALAXY
Mounting Type SMT
Length 1.60mm
Packaging TAPE&REEL
Technology Multilayer
Inductance 100nH
Diameter N/A
Width 0.80mm
Rohs ROHS

More Information

The GALAXY, 606733 surface-mount multilayer inductors are small electronic components used in circuits to block or resist the flow of alternating current (AC) while allowing direct current (DC) to pass. They are typically made of ferrite material and constructed with multiple layers to achieve a desired inductance value.

What Benefits Does It Offer?

  • Smaller size compared to traditional through-hole inductors, allowing for miniaturisation of electronic devices.
  • Improved performance characteristics like higher inductance and self-resonant frequency.
  • The assembly process is faster and more cost-effective due to surface mount technology.

Application Areas

  • Power management circuits in various electronic devices like laptops, smartphones, and tablets.
  • RF (radio frequency) circuits for filtering and impedance matching.
  • DC-DC converters for voltage regulation.
