AL0307-120K - INDUCTOR FIXED 12uH 3X8MM AXIAL TYPE THT

AL0307-120K
brand logo

HT Part No. HT194792

Mfr. Part No. AL0307-120K

Manufacturer: CORE MASTER

Technical Documents:

4 - In Stock pcs
Price:
£ 0.040
Units Per Unit Prices
1 - 4999 £ 0.040
5000 + £ 0.032
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package / Case Axial
Inductance 12uH
Current - Saturation (Isat) N/A
Mounting Type THT
Technology Wire Wound
Length 8.00mm
Packaging TAPE&REEL
Manufacturer CORE MASTER
Tolerance ±10%
Width N/A
Height N/A
Rohs ROHS
Series AL03
Pitch None
Shielding Shielded
Current Rating 350mA
DC Resistance (DCR) 800m Ohms
Applications General Purpose
Diameter 3.00mm
Operation Temperature N/A

More Information

The CORE MASTER AL0307-120K is a fixed inductor with a 12uH inductance featuring a 3x8mm axial through-hole technology (THT) design. It is a reliable component used in various electronic applications. A fixed inductor is a passive electronic device that stores power in a magnetic field when electric current flows through it. The CORE MASTER AL0307-120K is specifically designed to offer a stable 12uH inductance.

Unique Advantages of Using the CORE MASTER AL0307-120K, Fixed Inductor - 12uH 3x8mm Axial THT

  • Offers stable inductance under varying electrical conditions.
  • Robust construction suitable for various environmental conditions.
  • Designed to minimise electromagnetic interference.
  • Enhances performance in power supply circuits and signal filtering.

Typical Uses of the Fixed Inductor - 12uH 3x8mm Axial THT

The CORE MASTER AL0307-120K fixed inductor is a versatile and essential component in modern electronic circuits, offering reliability and efficiency across a range of applications, including:

  • Power Supplies: Used in switch-mode power supplies (SMPS) for energy storage.
  • Signal Filtering: Helps in filtering noise from signals in communication devices.
  • RF Circuits: Utilised in radio frequency applications for tuning and signal processing.
  • Automotive Electronics: Employed in automotive systems for various electronic control units (ECUs).

Different Variations of Power Inductors Stocked at Halltronics

    • Fixed Inductors: Provide a constant inductance value.
    • Variable Inductors: Allow adjustment of inductance.
    • Toroidal Inductors: Use a doughnut-shaped core.
    • Multilayer Inductors: Consists of several layers for higher inductance values.
