XAL4020-221MEC - INDUCTOR FIXED 220nH AEC-Q200

XAL4020-221MEC
brand logo

HT Part No. HT194742

Mfr. Part No. XAL4020-221MEC

Manufacturer: COILCRAFT

Technical Documents: Datasheet(datasheets)

365 - In Stock pcs
Price:
£ 1.13
Units Per Unit Price
1 - 999 £ 1.13
1000 + £ 1.02
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Inductance 220nH
Series XAL
Technology Power
Current Rating 12A
Length 4.00mm
Manufacturer COILCRAFT
DC Resistance (DCR) 5.81m Ohms
Width 4.00mm
Rohs ROHS
Mounting Type SMT
Shielding Shielded
Diameter N/A
Operation Temperature -40°C ~ +125°C
Packaging TAPE&REEL
Package / Case Non Standard
Pitch None
Current - Saturation (Isat) N/A
Tolerance ±20%
Applications Automotive(AEC-Q200)
Height 2.10mm

More Information

The Coilcraft 955742 is a fixed surface-mount inductor with a specific inductance of 5.81 microhenries (µH). These tiny workhorses are essential components in electronic circuits. Their surface-mount design enables space-saving integration into various electronic devices, making them ideal for miniaturised applications.

Potential Benefits

  • Precise inductance: They provide consistent and predictable electrical behaviour within circuits, ensuring reliable performance.
  • High reliability: Their construction guarantees long-lasting operation even in demanding electronic devices.

Versatile Usage

  • RF circuits: They play a crucial role in filtering, impedance matching, and signal tuning within radio frequency circuits.
  • Power electronics: They are employed in DC-DC converters, voltage regulators, and other power supply circuits to improve efficiency and stability.
  • Telecommunication devices: They can be found in filters, amplifiers, and other components of communication systems, contributing to signal clarity and transmission quality.
