SB560_AY_10001 - DIODE SCHOTTKY 5A 60V DO-201AD TAPED PANJIT

SB560_AY_10001
brand logo

HT Part No. HT299801

Mfr. Part No. SB560_AY_10001

Manufacturer: PANJIT

Technical Documents: Datasheet(datasheets)

7684 - In Stock pcs
Price:
£ 0.11
Units Per Unit Price
1 - 1249 £ 0.11
1250 + £ 0.097
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Diode Configuration Single
Average Rectified Current 5A
Package / Case DO201 (DO27)
Applications General Purpose
Packaging AMMO PACK
Series Schottky Rect.
Reverse Recovery Time (Trr) N/A
Operating Temperature -50°C~+125°C
Mounting Type THT
Polarity Cathode
Peak Repetitive Reverse Voltage (VRRM) 60V
Manufacturer PANJIT
Rohs ROHS

More Information

The SB560_AY_10001 is a high-performance, 5A, 60V single Schottky diode in a through-hole (THT) package. It combines low forward voltage drop, fast switching speed, and high surge current capability, making it ideal for a wide range of general-purpose applications.

Distinct Features & Benefits of SB560_AY_10001 - PANJIT Schottky Diode, 5A, 60V:

  • Low forward voltage drop (VF) for improved efficiency
  • Fast switching speed for reduced signal distortion
  • High surge current capability for handling transient voltage spikes
  • Reliable operation over a wide temperature range.

Typical Uses of SB560_AY_10001 - Schottky Diode, 5A, 60V:

  • Voltage rectification
  • Freewheeling diodes in DC-DC converters
  • Polarity protection circuits
  • Override circuits.
