CINETECH RB10A222J, RES.NETWORK 2.2K Ohms 5% 1/8W SIP9+1 THT

RB10A222J
brand logo

HT Part No. HT277874

Mfr. Part No. RB10A222J

Manufacturer: CINETECH

Technical Documents:

235 - In Stock pcs
Price:
£ 0.19
Units Per Unit Prices
2 - 1999 £ 0.19
2000 + £ 0.16
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Resistance Value 2.2K Ohms
Rohs N/A
Manufacturer CINETECH
Tolerance ±5%
Pin No 10 Pins
Circuit Type Single Common
Composition Thick Film
Working Voltage 200V
Length 25.40mm
Mounting Type THT
Applications N/A
Height 3.00mm
Packaging BULK&BOX
Keyword 2.2K
Package / Case Radial
Power 1/8W
Width 2.54mm
Temperature Coefficient ±100PPM/°C

More Information

The CINETECH RB10A222J is a resistor array that includes multiple resistors in a single package. Specifically, it has a resistance value of 2.2K ohms with a tolerance of 5%, a power rating of 1/8 watt per resistor, and is packaged in a SIP9+1 through-hole mount configuration. This component is commonly used in various electronic circuits for reducing space, simplifying PCB layout, and improving reliability by integrating several resistors in one array.

Possible Advantages of Using the CINETECH RB10A222J, Resistor Array

  • Space Saving: Integrates multiple resistors into a single compact package.
  • Simplified PCB Layout: Reduces the complexity of the board design.
  • Improved Reliability: Fewer components mean fewer potential failure points.
  • Ease of Assembly: Through-hole technology facilitates easy manual or automated soldering.

Where Can I Use the CINETECH RB10A222J, Resistor Array?

The CINETECH RB10A222J resistor array is a versatile and reliable component suitable for a wide range of electronic applications, including:

  • Digital and Analogue Circuits: Utilised for pull-up/pull-down resistors, signal termination, and voltage divider networks.
  • Consumer Electronics: Common in various devices like TVs, radios, and computers.
  • Industrial Control Systems: Ideal for use in control panels and automation equipment.
  • Telecommunication Equipment: Enhances performance in communication devices and networks.
