PT15NV02-103A2020-E-S
brand logo

HT Part No. HT193520

Mfr. Part No. PT15NV02-103A2020-E-S

Manufacturer: PIHER

Technical Documents:

5 - In Stock pcs
Price:
£ 0.27
Units Per Unit Prices
1 - 399 £ 0.27
400 + £ 0.23
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Tolerance ±20%
Temperature Coefficient ±300 ppm/°C
Rohs ROHS
Mounting Type THT
Mounting method Horizontal
Manufacturer PIHER
Resistance Value 10K Ohms
Number of Turn Single Turn
Shaft Without Shaft
Keyword karbon trimpot, japon tip trimpot, kombi trimpot, kombi kart trimpot
Series PT15
Size 15mm
Taper Linear
Rotors Oval
Adjust Method Vertical
Packaging BULK&BOX

More Information

The PT15NV02-103A2020-E-S is a high-performance trimmer potentiometer from Amphenol Piher, ideal for fine-tuning circuits in various electronic applications. This 15mm, single-turn component features a carbon film resistor element for smooth, reliable operation.

Distinct Features of Amphenol Piher PT15NV02-103A2020-E-S:

  • Compact 15mm size for space-constrained designs
  • Single-turn adjustment for quick and intuitive settings
  • 10KΩ resistance value with ±20% tolerance for broad usability
  • Horizontal mounting for easy integration into PCBs.

Benefits of PT15NV02-103A2020-E-S - Amphenol Piher Trim-Pot:

  • Enables precise adjustments in critical circuits
  • Saves valuable PCB real estate
  • Offers cost-effective control solution
  • Simple installation for efficient assembly.

Applications Information:

  • Calibration of electronic devices
  • Setting bias voltages in amplifiers
  • Adjusting signal levels in audio equipment
  • Controlling LED brightness
  • Trimming power supply voltages.
