TEXAS 74ACT16244DGGR, 6-Bit BUFFERS/LINE Drivers With 3-State Outputs

TEXAS 74ACT16244DGGR, 6-Bit BUFFERS/LINE Drivers With 3-State Outputs
74ACT16244DGGR
brand logo

HT Part No. HT210628

Mfr. Part No. 74ACT16244DGGR

Manufacturer: TEXAS

Technical Documents:

1 - In Stock pcs
Price:
£ 1.46
Units Per Unit Prices
1 - 1999 £ 1.46
2000 + £ 1.33
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Features 6-Bit BUFFERS/LINE Drivers With 3-State Outputs
Manufacturer TEXAS
Mounting Type SMT
Package / Case TSSOP48
Logic Type Buffer/Non-Inverting
Number of Buffers 4
Supply Voltage 4.5V to 5.5V
Output Type Three State
Output Current(High) 24mA
Output Current(Low) 24mA
Operating Temperature -40°C~+85°C
Rohs ROHS
Packaging TAPE&REEL

More Information

The TEXAS 74ACT16244DGGR is a robust 6-bit buffer/line driver designed to enhance the functionality of 3-state memory address drivers, clock drivers, and bus-oriented receivers and transmitters. This versatile device can be configured as four 4-bit buffers, two 8-bit buffers, or a single 16-bit buffer, offering flexibility in system design. Featuring true outputs and symmetrical output-enabled inputs, the 74ACT16244DGGR ensures reliable signal transmission.

Explore the Unique Advantages of the TEXAS 74ACT16244DGGR, 6-bit Buffer/Line Driver

  • Improved system performance and density
  • Versatile configuration options
  • Reliable signal transmission
  • Optimised PCB layout
  • Enhanced noise immunity

Typical Applications of the 6-bit Buffer/Line Driver

  • Industrial Control Systems
  • Telecommunication Infrastructure
  • Data Acquisition Systems
  • Peripheral Interfacing
  • Memory Address Buffering
  • Clock Signal Distribution
