HO 200-S/SP33-1106 - TRANSDUCER CURRENT 200A HALL EFFECT,OPEN LOOP

HO 200-S/SP33-1106
brand logo

HT Part No. HT257645

Mfr. Part No. HO 200-S/SP33-1106

Manufacturer: LEM

Technical Documents: Datasheet(datasheets)

149 - In Stock pcs
Price:
£ 16.73
Units Per Unit Price
1 - 19 £ 16.73
20 + £ 15.64
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Primary Signal Type AC/DC
Current Range (Max) ±500A
Voltage Range (Max) None
Frequency 0 ~ 100KHz
Technology Hall Effect,Open Loop
Sensitivity 2.3mV/A
Response Time 3.5us
Rohs ROHS
Supply Voltage 3.3VDC
Applications N/A
Operating Temperature -40°C ~ +105°C
Packaging TRAY
Manufacturer LEM
Mounting Type Free
Connversion Ratio N/A
Primary Nominal Value 200A
Secondary Signal N/A

More Information

The LEM 731427 is a current transducer specifically designed for use with transformers. This passive device converts high-amperage currents (in this case, up to 200 Amps) into a lower, safer voltage signal, allowing for easy measurement and monitoring of these currents using standard measuring instruments.

Possible Advantages

  • Enables safe and accurate measurement of high currents without needing a high-capacity ammeter.
  • Provides galvanic isolation between the high-power primary circuit and the secondary measurement circuit, improving safety and reducing ground loop noise.
  • Compact design compared to bulky high-current ammeters.

Usage Information

Primarily used in transformer circuits for:

  • Monitoring Transformer Loads: Tracks the current flowing through the transformer, aiding in overload protection and ensuring efficient operation.
  • Power Quality Analysis: Helps analyse current waveforms to identify potential issues like harmonics or power factor problems.
  • Industrial Automation & Control Systems: Provides current data for control systems in various industrial applications involving transformers.
