ANSEN AS49S-13.560-FC160F3, CRYSTAL 13.56MHZ HC49S 16pF 20ppm SHORT BULK

AS49S-13.560-FC160F3
brand logo

HT Part No. HT205345

Mfr. Part No. AS49S-13.560-FC160F3

Manufacturer: ANSEN

Technical Documents: Datasheet(datasheets)

Pre-order available (0 In Stock) pcs
Price:
£ 0.13
Units Per Unit Price
1 - 999 £ 0.13
1000 + £ 0.11
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Series AS49S
Frequency Tolerance ±20PPM
Equivalent Series Resistance (ESR) 40 Ohms
Height 3.60mm
Width 5.00mm
Rohs ROHS
Packaging BULK
Mounting Type THT
Frequency 13.56MHz
Capacitance 16pF
Applications N/A
Diameter N/A
Manufacturer ANSEN
Package / Case HC-49S
Frequency Stability ±50PPM
Length 11.50mm
Operating Temperature -20°C~+70°C

More Information

The ANSEN AS49S-13.560-FC160F3 is a high-performance, precision-engineered 13.56MHz quartz crystal housed in a compact HC49S package. This crystal is designed to deliver superior frequency stability and reliability, making it ideal for various electronic applications. With a load capacitance of 16pF and an impressive tolerance of 20ppm, the AS49S-13.560-FC160F3 ensures consistent performance across different environmental conditions. Its robust design allows it to operate in challenging environments, while the short bulk packaging makes it a convenient option for manufacturers requiring efficient assembly.

Potential Benefits of Using the ANSEN AS49S-13.560-FC160F3, Crystal

  • Built to withstand varied environmental conditions, enhancing product longevity.
  • Short bulk format for easy handling and efficient assembly in manufacturing.
  • Delivers consistent signal integrity and timing accuracy.
  • Suitable for a wide range of electronic applications due to its stable and reliable performance.
  • Provides a balance between quality and affordability.

Where Can I Use the ANSEN AS49S-13.560-FC160F3, Crystal?

  • Consumer Electronics: Suitable for clocks, microcontrollers, and other timing-sensitive devices.
  • Communication Devices: Ideal for RF communication modules and wireless transmitters.
  • Industrial Equipment: Used in control systems and monitoring devices requiring high precision and stability.
