744231091 - CHOKE COMMON MODE CMC 370MA 2LN 90 OHM SMD

744231091
brand logo

HT Part No. HT259884

Mfr. Part No. 744231091

Manufacturer: WURTH

Technical Documents: Datasheet(datasheets)

67 - In Stock pcs
Price:
£ 2.08
Units Per Unit Price
1 - 1999 £ 2.08
2000 + £ 1.89
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Package / Case 0805 (2012 Metric)
Number of Lines 2
Diameter N/A
Rohs ROHS
Mounting Type SMT
Packaging TAPE&REEL
Inductance 131nH
Applications Automotive(AEC-Q200)
Length 2.00mm
Operation Temperature -40°C ~ +125°C
Manufacturer WURTH
Filter Type Signal Line Filter
DC Resistance (DCR) 300m Ohms
Height 1.20mm
Series WE-CNSW
Pitch None
Technology Wire Wound
Shielding Shielded
Impedance 90 Ohms
Current 370mA
Tolerance ±25%
Width 1.20mm

More Information

The WURTH 744231091 is a surface-mount device (SMD) designed as a common mode choke (CMC), offering 90 Ohms of impedance and handling up to 370mA of current across two lines. A common mode choke (CMC) is an electromagnetic component used to filter out unwanted high-frequency noise signals in electronic circuits while allowing the desired low-frequency signals to pass.

Potential Advantages of Using the WURTH 744231091, Common Mode Chokes

  • Noise Reduction: Efficiently reduces electromagnetic interference (EMI) and radio frequency interference (RFI).
  • Compact Size: SMD design allows for space-saving in PCB layouts.
  • High Efficiency: Maintains signal integrity by filtering noise without significant signal loss.
  • Durability: Reliable performance in various environmental conditions due to robust construction.

Typical Uses of the Common Mode Chokes

  • Power Supplies: Used in switch-mode power supplies (SMPS) to minimise EMI.
  • Data Lines: Effective in filtering noise in high-speed data lines.
  • Consumer Electronics: Implemented in devices such as televisions, computers, and smartphones.
  • Industrial Equipment: Used in industrial control systems to enhance signal clarity and equipment reliability.
