2SC3585-T1B-AR45 - TRANSISTOR DIS.35mA 10V NPN SOT23 AMP SMT

2SC3585-T1B-AR45
brand logo

HT Part No. HT260785

Mfr. Part No. 2SC3585-T1B-AR45

Manufacturer: NEC

Technical Documents: Datasheet(datasheets)

2781 - In Stock pcs
Price:
£ 0.10
Units Per Unit Price
2 - 2999 £ 0.10
3000 + £ 0.089
  • secure-payment
  • visa
  • american-express
  • master-card
  • opayo

Product Specification

Product Attributes
Mounting Type SMT
Transistor Type Amplifier
Packaging TAPE&REEL
Current 35mA
Power Dissipation 200mW
Operating Temperature -65°C~+150°C
Manufacturer NEC
Package / Case SOT23
Voltage (Collector-Emitter) 10V
Applications N/A
Channel NPN
Current Temperature (IC) 25°C
Configuration Single
Junction Temperature (Tj) 150°C
Rohs ROHS

More Information

The NEC 2SC3585-T1B-AR45 is a high-frequency NPN bipolar junction transistor (BJT) designed for amplification and switching applications. It operates at a maximum collector current of 35mA and a collector-emitter voltage of 10V and is housed in a compact SOT-23 surface-mount package.

Possible Advantages of Using the NEC 2SC3585-T1B-AR45, NPN Bipolar Junction Transistor

  • Compact Size: The SOT-23 package allows for efficient use of PCB space.
  • High-Frequency Performance: Ideal for applications requiring rapid switching and high-frequency operation.
  • Low Power Consumption: Operates efficiently with minimal power loss.
  • Reliability: Manufactured to high standards, ensuring durability and consistent performance.

The NEC 2SC3585-T1B-AR45, NPN Bipolar Junction Transistor: Versatility in Applications

  • Amplifiers: Used in RF amplifiers for signal amplification.
  • Switching Circuits: Ideal for high-speed switching applications.
  • Oscillators: Suitable for use in oscillator circuits in communication devices.
  • Signal Processing: Employed in various signal processing applications due to its high-frequency capabilities.
  • Consumer Electronics: Utilised in devices like radios, TVs, and other high-frequency electronics.
